Medtronic Century Heart Lung Machine

The Medtronic Cobe Century Heart-Lung Machine is a modular system that incorporates features important to the perfusionist; a sturdy and compact design and easy-to-use components at an affordable price. The addition of the Bio-Console 560 centrifugal arterial pump and data management uses Spectrum’s Viper Vision option that can be easily configured onto the Medtronic Century Heart-Lung Machine.



• User-friendly system for advanced hemodialysis processes.
• Provides flexibility and medical information management.
• Integrated video display.
• The easy-to-use automation system provides prescription variability and other functions with push-button controls.
• Innovative cartridge blood tubing set design minimizes extracorporeal blood volume and saline requirements.
• Also features built-in arterial and venous pressure monitoring ports.



Perfusion Pumps Dimensions

• Length: 22.1 in (56 cm)
• Width: 7.1 in (18 cm)
• Height: 13 in (33 cm)
• Weight: 57 lbs (26 kg)s

Display Accuracy (RPM)

• 2% of reading or ± count whichever is greater (without load)

Power Power Consumption

• Maximum: 280 Watts
• Normal: 150 Watts

Leakage Current

• 100/115 VAC 12mA rms maximum
• 230 VAC 20 mA rms maximum

Occlusion

• 230 VAC 20 mA rms maximum

Console Bases Dimensions

• 3: Width: 27 in (69 cm); Weight: 97 lbs (44 kg)
• 4: Width: 34 in (86 cm); Weight: 105 lbs (48 kg)
• 5: Width: 41 in (104 cm); Weight: 113 lbs (51 kg)
• 6: Width: 48 in (122 cm); Weight: 121 lbs (55 kg)
• 7: Width: 55 in (140 cm)

Power Electrical Configurations

• North America: 50/60 Hz; 115 VAC
• United Kingdom: 50/60 Hz; 230 VAC
• European Continent: 50/60 Hz; 230 VAC
• Japan: 50/60 Hz; 100 VAC

Line Voltage Requirement

• ± 10% VAC

Circuit Breakers

• 14 Amp 17/115 VAC
• 10 Amp 230 VAC

Console Bases Dimensions Electronics Module

• Depth: 21 in (53 cm)
• Width: 7.1 in (18 cm)
• Height: 12 in (31 cm)
• Weight 30 lbs (13.6 kg)

Display Module

• Depth: 2.4 in (6 cm) Without Mount
• Depth: 8.7 in (22 cm) Without Fixed Mount
• Width: 13.3 in (34 cm)
• Height: 9.3 in (24 cm)
• Weight 9 lbs (4 kg) With Mount

Timers (3 Channels)

• Range: 00:00:00 to 99:59:59 (hours:minutes: seconds)
• Accuracy: ± 1% of elapsed time

Power Power Consumption

• Maximum: 80 Watts

Circuit Breakers

• 1.0 Amp at 100/115 VAC
• 0.6 Amp at 230 VAC

Leakage Current

• 100/115 VAC 20 mA rms maximum
• 230 VAC 40 mA rms maximum

Temperature Monitors (6 Channels) Display Range

• 0-50?

Display Resolution

• 0.1

Accuracy

• ± 1.0? With probe

Transducer Compatibility

• YSI-400 and YSI-500 with calibration
• Pressure Monitor – 2 Channels
• Pressure Alarm range: -200 to +400 mmHg
• Pressure limited range -210 to +450 mmHg
• Accuracy ±8 mmHg with transducer

Air Emboli Protection System (AEPS) AEPS Open Reservoir Level Detection

• Sensitivity: Within diameter of transducer (1 cm/0.4in.)~ 0 40 Hct. blood temperature 10-40?

AEPS Bubble Detection Sensitivity

• > 0.7 ml at flow rates < 6 5 Ipm with 3/8” x 3/32” tubing (PVC only)
• > 0.3 ml at flow rates <3.0 |pm with 1/4” x 3/32” tubing (PVC only)
• Response time for pump control: <1 second
• Arterial line tubing compatibility: 3/8” x 3/32” or 1/4” x 3/32” (PVC only)

Cardioplegia Delivery System Display Range



• The last volume delivered: 0 to 9999 ml
• Total volume delivered: 0 to 9999 ml
• Time since last delivery: 0 to 99:59:59 (hours: minutes: seconds)
• Accuracy: ±10% of desired volume
