Product Details
Type
Catheter Guide
Country of Origin
India
Features:
- Amber™ offers high performance in delivering various devices through it by virtue of its inner PTFE lining which is highly lubricious
- Multi-segment design of device which makes it maximum kink resistant, offers high level flexibility for gentle cannulation and great torquability from hub to distal end of Catheter
- 3 layered construction
- Flat Stainless-Steel braiding
- Relatively larger inner lumen for better space for device delivery
- Outstanding kissing Balloon Capabilities
- Optimal balance and superior vessel alignment
- Excellent backup support
- Smooth surface finish to prevent vascular spasm
- Atraumatic soft tip to minimize vessel damage
- Excellent radio-opacity
- Length: 100 cm / 110 cm; with or without side holes
Technical Specifications
| Parameter | Specification |
| Available Lengths | 100 cm /110 cm (With or without side holes) |
| Outer Diameter | 5 Fr – 1.70 mm |
| 6 Fr – 2.00 mm | |
| 7 Fr – 2.32 mm | |
| Inner Diameter | 5 Fr – 1.40 mm |
| 6 Fr – 1.78 mm | |
| 7 Fr – 2.00 mm | |
| Mesh Braid Material | Stainless Steel Flat Braid |
| Pressure Limit | 950 psi |
| Units per box | 1 No’s |
Ordering Information
| Shapes/Size | 5 Fr | 6 Fr | 7 Fr |
| Judkins Left – 3.0 | GJL-3000-5Fr | GJL-3000-6Fr | GJL-3000-7Fr |
| Judkins Left – 3.5 | GJL-3500-5Fr | GJL-3500-6Fr | GJL-3500-7Fr |
| Judkins Left – 4.0 | GJL-4000-5Fr | GJL-4000-6Fr | GJL-4000-7Fr |
| Judkins Left – 4.5 | GJL-4500-5Fr | GJL-4500-6Fr | GJL-4500-7Fr |
| Judkins Left – 5.0 | GJL-5000-5Fr | GJL-5000-6Fr | GJL-5000-7Fr |
| Judkins Right – 3.0 | GJR-3000-5Fr | GJR-3000-6Fr | GJR-3000-7Fr |
| Judkins Right – 3.5 | GJR-3500-5Fr | GJR-3500-6Fr | GJR-3500-7Fr |
| Judkins Right – 4.0 | GJR-4000-5Fr | GJR-4000-6Fr | GJR-4000-7Fr |
| Judkins Right – 4.5 | GJR-4500-5Fr | GJR-4500-6Fr | GJR-4500-7Fr |
| Judkins Right- 5.0 | GJR-5000-5Fr | GJR-5000-6Fr | GJR-5000-7Fr |
| Extra Back up – 3.0 | GXB-3000-5Fr | GXB-3000-6Fr | GXB-3000-7Fr |
| Extra Back up – 3.5 | GXB-3500-5Fr | GXB-3500-6Fr | GXB-3500-7Fr |
| Extra Back up – 4.0 | GXB-4000-5Fr | GXB-4000-6Fr | GXB-4000-7Fr |
| Extra Back up – 4.5 | GXB-4500-5Fr | GXB-4500-6Fr | GXB-4500-7Fr |
| Extra Back up – 5.0 | GXB-5000-5Fr | GXB-5000-6Fr | GXB-5000-7Fr |
| Ikari – 3.0 | GIK-3000-5Fr | GIK-3000-6Fr | GIK-3000-7Fr |
| Ikari – 3.5 | GIK-3500-5Fr | GIK-3500-6Fr | GIK-3500-7Fr |
| Ikari – 4.0 | GIK-4000-5Fr | GIK-4000-6Fr | GIK-4000-7Fr |
| Ikari – 4.5 | GIK-4500-5Fr | GIK-4500-6Fr | GIK-4500-7Fr |
| Ikari – 5.0 | GIK-5000-5Fr | GIK-5000-6Fr | GIK-5000-7Fr |
| Amplatz Left – AL1 | GAL-AL01-5Fr | GAL-AL01-6Fr | GAL-AL01-7Fr |
| Amplatz Left – AL2 | GAL-AL02-5Fr | GAL-AL02-6Fr | GAL-AL02-7Fr |
| Amplatz Left – AL3 | GAL-AL03-5Fr | GAL-AL03-6Fr | GAL-AL03-7Fr |
| Amplatz Right – AR1 | GAR-AR01-5Fr | GAR-AR01-6Fr | GAR-AR01-7Fr |
| Amplatz Right – AR2 | GAR-AR02-5Fr | GAR-AR02-6Fr | GAR-AR02-7Fr |
| Amplatz Right – AR3 | GAR-AR03-5Fr | GAR-AR03-6Fr | GAR-AR03-7Fr |
| Multi Purpose – 3.0 | GMP-3000-5Fr | GMP-3000-6Fr | GMP-3000-7Fr |
| Multi Purpose – 3.5 | GMP-3500-5Fr | GMP-3500-6Fr | GMP-3500-7Fr |
| Multi Purpose – 4.0 | GMP-4000-5Fr | GMP-4000-6Fr | GMP-4000-7Fr |
| Multi Purpose – 4.5 | GMP-4500-5Fr | GMP-4500-6Fr | GMP-4500-7Fr |
| Multi Purpose – 5.0 | GMP-5000-5Fr | GMP-5000-6Fr | GMP-5000-7Fr |
| Barbeau – 3.0 | GBR-3000-5Fr | GBR-3000-6Fr | GBR-3000-7Fr |
| Barbeau – 3.5 | GBR-3500-5Fr | GBR-3500-6Fr | GBR-3500-7Fr |
| Barbeau – 4.0 | GBR-4000-5Fr | GBR-4000-6Fr | GBR-4000-7Fr |
| Barbeau – 4.5 | GBR-4500-5Fr | GBR-4500-6Fr | GBR-4500-7Fr |
| Barbeau – 5.0 | GBR-5000-5Fr | GBR-5000-6Fr | GBR-5000-7Fr |
